Features of Brinell Rockwell Vickers Tester
1. The body part of the product is formed in one go through a casting process and has undergone long-term aging treatment. Compared to the panel assembly process, long-term use has minimal deformation and can effectively adapt to various harsh environments;
2. Automotive paint, with high quality and strong scratch resistance, remains shiny and new after years of use;
3. Ready to use upon startup, without the need to install weights;
It adopts a large screen touch LCD display interface, with rich display content and convenient operation;
4. The electronic closed-loop control applies the test force, with an accuracy of 5 ‰. The force sensor controls the test force, fully realizing the automatic operation of applying, maintaining, and removing the test force;
5. The hardness values of each scale can be converted to each other through measurement;
6. The body is equipped with a micrometer and a high-definition micro optical system to make the observation readings clearer and reduce errors;
7. Equipped with a built-in micro printer and optional RS232 data cable, it can be connected to the computer through a super terminal to export measurement reports.
8. Equipped with three testing methods of Brinell, Rockwell, and Vickers, with multi-level testing force, it can meet various hardness testing requirements;
Application of Brinell Rockwell Vickers Hardness Tester
Suitable for measuring the hardness of quenched, tempered, annealed, cold hard castings, malleable castings, hard alloy steel, aluminum alloy, copper alloy, bearing steel, etc.
Technical parameters,
Rockwell Scales | Initial Testing Force | 3kgf (29.42N),10kg（98.07N） |
| Total test force | 15kgf (147.1N), 30kgf (294.2N), 45kgf (441.3N), 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N) |
| Indenter | Diamond Rockwell indenter、Ф1.5875mm Ball indenter |
| Scales | HRA、HRB、HRC、HRD、HRE、HRF、HRG、HRH、HRK、HRL、HRM、HRP、HRR、HRS、HRV、HR15N、HR30N、HR45N、HR15T、HR30T、HR45T、HR15X、HR30X、HR45X、HR15Y、HR30Y、HR45Y、HR15W、HR30W、HR45W |
| Maximum height of the specimen | 180mm |
Brinel Scales | Testing Force | 5、6.25、10、15.625、30、31.25、62.5、 100、125、187.5Kgf |
| Scales | HBW1/5、HBW1/10、HBW1/30、HBW2.5/6.25、HBW2.5/15.625、 HBW2.5/31.25、 HBW2.5/62.5 、HBW5/31.25、HBW10/100、HBW2.5/187.5、HBW5/62.5、HBW5/125 |
| Indenter | φ2.5mm、φ5mm Ball indenter |
| Eyepiece magnification | 15X |
| Objective magnification | 2.5X、5X |
| Maximum height of the specimen | 165mm |
Vickers Scales | Testing Force | 3、5、10、20、30、40、50、60、80、100、120Kgf |
| Indenter | Diamond Vickers indenter |
| Scales | HV3、HV5、HV10、HV20、HV30、HV40、HV50、HV60、HV80、HV100、HV120 |
| Eyepiece magnification | 15X |
| Objective magnification | 10X |
| Maximum height of the specimen | 165mm |
Hardness tester host | Display method | LCD digital display |
| Distance from the center of the pressure head to the body | 160mm |
| External dimensions of hardness tester | 550*230*780mm |
| Instrument weight approximately | 80KG |
| Auxiliary functions | Storage function; Built in printer; Hardness conversion between different hardness scales |
| Interface | RS232 |
| supply voltage | AC220V±5%，50～60Hz |
Standard configuration
Name | Quantity | Name | Quantity |
Hardness tester | 1 | Diamond Rockwell indenter | 1 |
Diamond Vickers indenter | 1 | φ1.5875mm ball indenter φ2.5mm Hard alloy ball indenter φ5mm Hard alloy ball indenter | Each 1 |
HRC standard hardness block | 3 | Allen key 2.5MM | 1 |
HRB standard hardness block | 1 | big、small、V-shaped worktable | Each 1 |
HRA standard hardness block | 1 | External lighting | 1 |
HVstandard hardness block | 1 | Slide work table | 1 |
HB standard hardness block | 1 | Microscopium (including interior lamp) | 1 |
Horizontal adjustment screw | 4 | Level gauge | 1 |
Digital micrometer eyepiece | 1 | 2.5X、5X、10X objective | Each 1 |
Power cord | 1 | Fuse 2A | 2 |
