TS3.5-4.5L/h Sterilizer and Distiller

Specification of TS3.5-4.5L/h Sterilizer and Distiller

•  Lanetech TS3.5-4.5L/h Sterilizer and Distiller – Wall-mountable design enables continuous, automatic production of clean distilled  water with low operating cost.

•  Operation principle – Tap water enters at the bottom of the condenser coil, flows through the coil, and enters the vaporizer pan. Overflow height can be preset for precise water level control.

•   Efficient steam generation – Steam generated in the vaporizer pan passes through a multi-stage guide plate, changing direction three times before entering the condenser—effectively preventing untreated tap water from mixing with distilled output.

•   Enhanced water purity – This three-direction flow separation ensures that chemical impurities and contaminants from tap water are not carried over into the final distilled water, a critical factor for achieving high-quality distillate.

•   Materials and construction – Vaporizer pan, condenser, and guide plate are constructed from stainless steel for durability, corrosion resistance, and hygienic operation. Outer cover is made of heat-resistant borosilicate glass for safe visual monitoring; all electrical components feature safety cut-off switches.

Parameter of TS3.5-4.5L/h Sterilizer and Distiller
